| Model No | Torque Range | Machine Screw Dia | Tapping Screw Dia | Standard Deviation |
Free
Speed
|
Avg.Air
Cons
|
Length
|
Weight
|
Air
Pressure
|
Air Hose Bore
|
| 型號 | 扭力范圍 | 機械螺絲 | 自攻螺絲 | 扭力精度 | 轉速 | 耗氣量 | 長度 | 凈重 | 使用壓力 | 進氣管尺寸 |
| Kgf-cm | % | rpm | m3/min | mm | g | kg/cm2 |
mm
|
|||
| BLP-T10PB | 0.5-2 | M1.0-M2.2 | M1.1-M1.7 | ±3 | 1000 | 0.28 | 180 | 480 | 6.0 | 5.0 |
| BLP-T20PB | 1-8 | M1.7-M3.3 | M1.3-M2.7 | ±3 | 1000 | 0.28 | 180 | 480 | 6.0 | 5.0 |
| BLP-T30PB | 3-17 | M2.2-M4.2 | M1.7-M3.2 | ±3 | 1800 | 0.28 | 180 | 480 | 6.0 | 5.0 |
| BLP-T35PB | 3-20 | M2.2-M4.5 | M1.7-M3.5 | ±3 | 2200 | 0.28 | 180 | 480 | 6.0 | 5.0 |
| BLP-T40PB | 5-30 | M2.8-M5.0 | M2.2-M4.0 | ±3 | 1000 | 0.28 | 180 | 480 | 6.0 | 5.0 |
| BLP-T45PB | 8-40 | M3.3-M5.7 | M2.7-M4.4 | ±3 | 800 | 0.28 | 180 | 480 | 6.0 | 8.0 |
| BLP-T48PB | 5-45 | M2.8-M5.8 | M2.2-M4.7 | ±3 | 1800 | 0.55 | 215 | 790 | 6.0 | 8.0 |
| BLP-T50PB | 7-50 | M2.9-M6.0 | M2.6-M4.9 | ±3 | 1400 | 0.55 | 215 | 790 | 6.0 | 8.0 |
| BLP-T55PB | 7-65 | M2.9-M6.4 | M2.6-M5.4 | ±3 | 1000 | 0.55 | 215 | 790 | 6.0 | 8.0 |
| BLP-T60PB | 15-95 | M4.1-M7.0 | M3.1-M6.0 | ±3 | 550 | 0.55 | 215 | 790 | 6.0 | 8.0 |
| BLP-T65PB | 30-180 | M5.0-M9.3 | M4.0-M7.2 | ±3 | 300 | 0.55 | 215 | 810 | 6.0 | 8.0 |
| BLP-T68PB | 50-280 | M6.0-M11.0 | M4.9-M8.7 | ±3 | 250 | 0.55 | 215 | 810 | 6.0 | 8.0 |
